Automatic Paper Core Cutter Cardboard Tube Cutting Machine

Product Description

Product Description Automatic Paper Core Cutter Cardboard Tube Cutting Machine   Techinical Parameters:

Jumbo Tube length

2000mm

Paper Tube Inner Dia

50-152mm

Paper Tube Thickness

4-15mm

Cutting Length

10-2000mm

Cutting Speed

60 cuts/min

Turret Movement Speed

1.8 m/min

Working Pressure

0.6Mpa

Voltage

380V 3 Phase 50Hz

Power

3kw

Cutting Mode

Paper tube turn; knives and axes do not turn

Operator

1 person

Mould

2 sets

Uploading/Unloading

Hand control

Dimension

Main Body: 3900mm*1000mm*2100mm

Weight

1200kgs

  Specifications:

Ø  Machine adopts Delta PLC and Touch screen control system, all the parameters are displayed on the touch screen, and it runs automatically.

Ø  It adopts Shenzhen Zhengxuan frequency inverter and Xinling motor(Zhejiang) to control.

Ø  It adopts 2 sets Yaskawa servo motor(Japan), one servo motor(0.85kw) to control cutter blade, the other servo motor(1kw) is moved, it control machine head.

Ø  It adopts 2 sets Yaskawa servo driver, one servo driver to control (1kw) to control cutter blade, the other servo driver(1kw) is moved, it control machine head.

Ø  It adopts double round blades to cutter.

Ø  It adopts 2 pieces ABBA mobile screw(Taiwan) to separate control cutter and machine head.

Ø  It adopts 2 sets Hiwin move the slider and track(Taiwan) to separate control cutter and machine head.

Ø  It adopts Hugong Signal element, Delixi Electrical components and Zhejiang Xingchen Pneumatic Components.

Ø  Paper tube clamping adopts automatic chucks.

Packaging & Shipping Packing: Automatic Paper Core Cutter Cardboard Tube Cutting Machine is with stretch film wrapping and wooden case. As for the machine, we will supply one year guarantee, whole life technical support, a set of tools, a box of vulnerable parts, English Manu, Inverter Manu and Electrical Schematic Diagram.    Delivery: Within 40 working days after the receipt of 30% payment by T/T. Automatic Paper Core Cutter Cardboard Tube Cutting Machine. Recommended Products Our Customers Exhibition Company Information Jota Machinery Industrial(Kunshan) Co.,Ltd is a long established engineering company combined with science,research, development, production and management. It is specializing in plastic & paper packing machinery with more than 30 years experiences in China.   We supply all kinds of packaging machines to satisfy the stringent requirements for Health and Safety, and meet the latest European CE standards. We provide customers with professional pre and after sales services, and to guarantee complete satisfaction of the equipments installed all over the world. Our Services  Q1: What's payment terms ,trade terms you accept? Usually we appreciate T/T 30% deposit, then 70% balance is paid before shipment, we usually offer FOB ningbo price. We also accept other ways like L/C, wetern union, and do CFR&CIF etc.   Q2. Does it easy to operate and what can i do if it doesn't work? First, our machine is stable and easy to operate by one man, what you do is just learn some basic things like loading the jumbo roll paper, start the machine and cutting the paper. We will sent you manual and video. Our suggestion is for you to visit our factory to learn more things by yourself, and if something goes wrong, you can call us, video-chat, or email us. We will give solutions within 36 hrs. Our engineer also can be distributed to overseas as you required.   Q3. If the machine's spare parts broken ,where can i get? We will give you the spare parts which is vulnerable, and some critical parts like gear box. Our quality is good, in case broken within one year, we will sent you for free. FAQ  1, Are you trading company or manufacturer? We are a manufacturer, and also provide business solutions to all the friends.   2, Do you have quality certificate? Yes we have CE, SGS etc.   3, What's the delivery time? Around 20~30days, however, based on order.   4, Can you help us to buy other goods? Sure of that, it is our honor to work for you, and control the goods quality.

Contact us if you need more details on Automatic Paper Core Cutter Cardboard Tube Cutting Machine. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Strech Film Core Paper Tube Paper Core Cutter、Toilet Roll Core Tissue Paper Core Paper Pipe Cardboard Tube Cutting Machine. If these products fail to match your need, please contact us and we would like to provide relevant information.
